1. The lamp body is filled with high-quality environmental protection PU glue, which will not affect the internal circuit of the lamp even if it is directly soaked in rain.
2. The lamp body adopts physical waterproof structure design. After the lamp is heated, it can automatically form hot gas convection to keep the lamp temperature below 60 °.
3. The overall streamline design of the lamp has undergone multiple process treatments, so as to achieve the combination of high-strength ultra white tempered glass and arc lamp body
4. The reasonable electronic circuit design of International LED chip combined with excellent heat dissipation structure ensures the service life of lamps,
5. Excellent support structure design ensures flexible adjustment of lamps
6. In addition to the novel appearance design, the bottom of the aluminum substrate and the shell are hard linked to ensure good contact between the lamp plate and the shell, which can quickly dissipate heat, so as to reduce light attenuation and delay service life.
7. The surface adopts high-temperature polyester powder spraying process to ensure the weather resistance of lamps for long-term outdoor use. The flexible production process can customize the appearance color according to the engineering situation.
8. The lens customized by international lens manufacturers provides technical and hardware support for the optimization of the secondary optical lens of the lamp, ensuring that the lamp has excellent optical efficiency performance!
9. High temperature and high humidity (temperature 85 ° C and humidity 85) aging test for more than 2000 hours to ensure the reliable performance of lamps in outdoor environment for long-term use.
功 率: Power: | 12W/15W | |
输入电压 lnput Voltage | DC24V | |
外观颜色 Appearance | 与建筑同色 | |
主体材质 Main Material | 6063铝+超白钢化玻璃 | |
产品尺寸 product size | 1000*28*35MM(不含支架高度) | |
防护等级 IP Code | IP65 |
芯片规格 The LED chip specification | CREE/EPISTAR | |
色温 Color Temperature | 单色可选/RGBW | |
光通量 Luminous flux | 1020ML(10*45°) | |
使用寿命 life / duration | >50000小时 | |
光束角 Beam Angle | 5-120°/双角度 |
工作环境 Operating Environment | —45°C 到65°C |
配置选型参数:
序号 | 型号 | 光源类型 | 光源色温 | 光源数量 | 系统功率 | 芯片/光源品牌 |
1 | HT-XQ2835 | SMD 5050LED | 单色可选 | 48 | 12W | CREE / OSRAM |
2 | HT-XQ2835 | SMD 5050LED | 单色可选 | 60 | 15W | CREE / OSRAM |
3 | HT-XQ2835 | RGB 三合一 LED | RGB | 48 | 12W | CREE / OSRAM |
4 | HT-XQ2835 | RGBW 四合一 LED | RGBW | 48 | 12W | CREE / OSRAM |
5 | 备注 | 如以上配置不在选定范围内, 可根据要求特别定制。 |
